Merlin 62

Merlin 62
Description
The Merlin 62 is equally at home in municipal and contractor environments. Designed for mounting on a truck chassis in the 10-16 tonne GVW range, the Merlin 62 is capable of delivering an unrivalled payload in its class. Our innovative single-engine system combines with our intuitive CANbus control system to offer users unrivalled control of their sweeper operation. The Merlin 62 allows the operator to control a constant sweeping speed from 0-20 mph whilst the chassis engine runs at an optimal 1200rpm - this solution allows the Merlin 62 to deliver low fuel consumption and low emissions whilst still supplying powerful and reliable suction performance. SINGLE ENGINE, LOWER EMISSIONS. Scarab can justifiably claim to be the pioneer of the truck-mounted sweeper powered from a single-engine. Operating the whole machine from the engine of the truck chassis provides many advantages, including reduced fuel consumption, decreased noise and engine pollution, less weight, greater payload and reduced maintenance. FLEXIBLE TRUCK MOUNTED SOLUTIONS.
The Merlin 62 is just one of Scarab's expertly engineered truck-mounted road sweeping solutions. Because of its flexibility, the Merlin 62 can be fitted to a wide choice of chassis. SUCTION PERFORMANCE. A stainless steel 905.5mm roof-mounted impellor is positioned to produce a short, efficient airflow path for high suction performance and reduced power consumption. ROBUST HOPPER. The hopper is completely manufactured from strong, corrosion and abrasion-resistant 4003 stainless steel. The hopper is shot blasted, a two-pack epoxy primer is applied and a hard-wearing topcoat provides a superior finish. The particulate screening is hinged and swings down to provide access to the operator for cleaning. SWEEPING CAPABILITY. The Merlin 62 is available in both single and optional dual sweep configuration When the suction nozzle, side brush and widesweep functions are in operation the Merlin 62 can sweep up to 2365mm width. However, the brushes can reach an impressive 3200mm span when simultaneously dual sweeping. INTUITIVE CONTROL.
The intuitive CANbus controls and a colour monitor provide comprehensive feedback to both the driver and service team. The clear display indicates the sweeping configuration and vehicle condition - while also highlighting warnings and service reminders. Our real-time monitoring and data logging provide valuable assistance in troubleshooting technical problems and help keep your machine running at its most efficient.
Sweep Width: 2365 mm single/3200 mm dual
Specifications
Manufacturer | Scarab-Fayat |
Size | 10-16 tonne GVW |
Sweeping Speed | 0-20 mph / 0-32 kph |
Hopper Capacity | 6.2 cubic metres |
Water Tank | 1250 litres |
Engine | Single Engine |
Typical Payload | 5500-8500 kg |
Sweep Width | 2365 mm single/3200 mm dual |
